Baja Designs XL Racer Edition LED Pod Pair, Clear Racer Spot, Wiring Harness Included

The Baja Designs 687802 XL Racer Edition package includes two clear Racer Spot LED pods, a wiring harness and mounting hardware. Each light is rated at 2,800 lumens and uses high-intensity LEDs with High-Speed Spot reflectors. This universal off-road pair is intended for a custom auxiliary-light installation, with Baja Designs describing its beam as suited to lighting zone 5.

Configuration and included contents

• Two complete XL Racer Edition LED light pods
• Clear Racer Spot lenses; beam-pattern field: Racer Edition Spot
• Black hard-anodized and powder-coated cast aluminum housings
• Wiring harness included
• Mounting hardware included; stainless-steel material listed
• Universal application; confirm mounting space and electrical compatibility
• Manufacturer part number / store SKU: 687802

The part-specific descriptions identify XL Racer Edition. One product-type attribute calls the package XL80 Racer Edition; that alternate label appears in the source but does not establish that these are standard XL80 pods or authorize substituting standard XL80 output figures. This package contains two complete lights, not replacement lenses.

Specifications per light

• Manufacturer-listed output: 2,800 lumens per pod
• Power: 45.54W per pod
• Current draw: 3.3A per pod
• Four high-intensity LEDs per light
• Forward-projecting LED lighting
• Lighting modes: High Beam / Dimming Feature (20%)
• Listed dimensions: 4.43 inches long × 4.43 inches high × 3.65 inches deep per pod
• Product weight: 2.45 lb per pod
• Average rated life: 49,930 hours
• Built-in overvoltage protection

The output, power and current figures above apply to each light, not the whole pair. The 20% dimming option is listed without separate dimmed lumen, wattage or current figures, so none are calculated here. No operating voltage range or measured beam-distance figure is supplied in this exact-part record.

Manufacturer range comparisons

Baja Designs claims an 85% increase in range with next-generation LEDs, but the source does not identify the baseline for that percentage. It separately claims that the XL Racer throws light 40% farther than the XL Pro. These are manufacturer comparison claims, not absolute distance measurements, and the percentages are not combined.

Wiring and high/low control

A wiring harness is explicitly included, but its part number, length and switch arrangement are not identified. The manufacturer specifically directs users to harness 640119 for hi-lo functionality. The supplied-harness listing does not establish that 640119 or high/low controls are included; confirm the required control arrangement before installation.

The compatible-products list separately names 640094 upfitter wiring, 640119 Hi/Low wiring, 660060 Off Road Mode Switch wiring and 613608 and 613609 splitters. These accessory listings are not additional confirmed package contents. Follow the manufacturer's installation instructions for mounting, connections and operation.

Construction and durability

• Hard-anodized and powder-coated cast aluminum housings
• Powder-coated cast aluminum bezels
• Hardcoated polycarbonate lenses
• Stainless-steel mounting hardware
• Manufacturer-listed durability: exceeds MIL-STD810G testing
• Manufacturer-listed impact resistance: IK10
• Manufacturer-listed water resistance: IP69K, described as waterproof up to 9 feet and pressure washable

Optional accessories and manufacturer coverage

Rock guards, amber and clear covers, alternative lens kits and anti-theft hardware are separately listed accessories or associated products, not additional confirmed contents. They do not change the supplied clear Racer Spot configuration.

Baja Designs lists a Limited Lifetime Warranty and a 30-day money-back Satisfaction Guarantee, subject to its terms.
