Baja Designs S1 LED Light Pod, Baja Amber Wide Cornering Single, Black Housing, No Harness

The Baja Designs 380015 S1 packs a specialized reflector and single LED into a compact 2.1-inch housing. Its Baja Amber Wide Cornering lens provides the part-specific beam configuration, with manufacturer-listed output of 2,320 raw lumens. The small footprint offers mounting flexibility when space is limited.

Configuration and contents

• One S1 LED auxiliary light pod
• Baja Amber main lens, Wide Cornering beam
• Black housing, hard-anodized and powder-coated cast aluminum
• Powder-coated cast-aluminum bezel
• Hardcoated polycarbonate lens
• One forward-projecting LED
• Stainless-steel mounting hardware included
• Wiring harness not included
• Manufacturer part number / store SKU: 380015

This is a single standard S1 pod, not a pair, flush-mount version, Spot or Work/Scene model. Black refers to the housing; Baja Amber refers to the main lens.

Per-light specifications

• Output: 2,320 raw lumens
• Electrical draw: 19.596W / 1.42A
• Listed voltage range: 9–28V
• Length, height and depth: 2.1 inches each
• Light weight: 0.4 lb
• Manufacturer-listed average rated life: 49,930 hours
• Built-in overvoltage protection

Dimensions and weight above describe the light, not its shipping package.

Manufacturer-listed durability

• IP69K, described as waterproof up to 9 feet and pressure washable
• IK10 mechanical-impact compliance
• Exceeds MIL-STD810G testing, according to Baja Designs

Installation and separate wiring

Universal fitment does not establish vehicle-specific brackets or a plug-and-play electrical connection. Check mounting clearance and electrical compatibility, select appropriate wiring and follow the manufacturer's instructions. This auxiliary pod is not represented as a DOT headlight replacement.

The source lists compatible wiring products 613600 (harness/splitter, three-light maximum), 613607 (splitter), 613609 (55-inch harness/splitter), 640093 (upfitter harness), 640117 (on/off harness/splitter), 640164 (Hi/Low wiring harness) and 640165 (10-foot extension). All are separate products. The Hi/Low accessory name alone does not establish built-in high/low modes in this light; confirm the required harness and control configuration before purchase.

Optional accessories

Separately listed rock guards are 388001 (black), 388002 (amber) and 388003 (clear). Optional lens kits are 660116 (clear Spot), 660117 (clear Wide Cornering), 660118 (amber Wide Cornering) and 660119 (clear Work/Scene). None of these accessories is included with the pod.

Manufacturer coverage

Baja Designs lists a 30-Day Money Back Satisfaction Guarantee and Limited Lifetime Warranty, subject to its terms.
