Baja Designs OnX6+ 10-Inch Lower Grille Kit, 2017-20 Ford F-150 Raptor Gen 2, Clear Driving/Combo, Upfitter Harness

The Baja Designs 447557 OnX6+ 10-inch lower grille light bar kit adds forward illumination to the 2017–20 Ford F-150 Raptor while keeping the bar low in the grille. The included clear Driving/Combo bar delivers a manufacturer-listed 10,817 raw lumens, and the supplied harness connects the light to the truck's factory upfitter switches.

Vehicle application

• 2017–20 Ford F-150 Raptor
• Mounting location: lower grille
• Control connection: factory upfitter switches through the included harness
• Manufacturer part number / store SKU: 447557

Included contents

• One OnX6+ 10-inch LED light bar, clear Driving/Combo, part 451003
• Lower grille mounting brackets
• Wiring harness for connection to the factory upfitter switches

Clear identifies the lens configuration, and Driving/Combo identifies the supplied beam pattern. The manufacturer mentions high-speed spot reflectors within the bar, but explicitly identifies this kit's bar as Driving/Combo, not a Spot-only configuration. A separate toggle switch is not identified in the contents.

Output and installation

Baja Designs lists 10,817 raw lumens for the included light bar and describes coverage across its lighting zones 1, 2, 3 and 4. This is the output of the single bar, not a per-LED figure.

The manufacturer describes installation as requiring minimal modifications. The supplied brackets are specifically designed for this 10-inch OnX6+ bar and will not accept another light. Confirm the vehicle's factory upfitter wiring configuration and follow the manufacturer's installation instructions.

This part-specific record does not provide electrical draw, voltage range or actual light-bar dimensions beyond its nominal 10-inch size. Shipping-box dimensions and shipping weight are not measurements of the light bar.

Manufacturer coverage

Baja Designs lists a 30-day satisfaction guarantee and a Limited Lifetime Warranty, subject to their terms.
